TRABT1500 | Laird Antenex VHF Omni Antenna 150-168Mhz - 3/4 Inch NMO. Ground Plane Required. Soup Can Style Phantom. Black

  • $88.58
    Unit price per

TRABT1500


9 Can ship immediately
Volume Price Breaks
Quantity: Unit Price:
10 $83.20
25 $79.59
100 $76.27
250 $72.73
500 $72.26
Lead time for qty above 9:  Ships in 8-10 Weeks

TRABT1500 | Laird Antenex VHF Omni Antenna 150-168Mhz - 3/4 Inch NMO. Ground Plane Required. Soup Can Style Phantom. Black

TRABT1500 | Laird Antenex VHF Omni Antenna 150-168Mhz - 3/4 Inch NMO. Ground Plane Required. Soup Can Style Phantom. Black

More InfoDocumentsSpecifications Reviews

Note: Field tuning is REQUIRED for this antenna, see tuning guide below.

This unit is a Black 'Phantom' style / Stealth VHF Omni-directional antenna with standard 3/4 inch NMO-mobile mount operating at 150-168Mhz range. This antenna is a 'Soup Can' style and offers a powerful punch with up to 3 dBi of gain. Please note that this model REQUIRES mounting on metallic ground plane for best performance. The Phantom series offers ultra-rugged ABS construction which is virtually indestructible and has a proven track record for holding up in the field for many years in any conditions. 3/4 inch NMO Cable kits and mounting hardware or magnetic mounts for this antenna can be purchased separately.

*This Antenna Requires a NMO Mount. Please click here to find all Thru-Hole NMO mounts or Magnetic NMO Mounts we carry.



More Information

The low profile, omni-directional, Phantom Antenna product line, was originally introduced by Antenex, and later acquired by Laird Technologies. The Phantom Antenna's patented technology is beneficial when high performance is desired and extreme ruggedness and low profile is required. The antenna's revolutionary design features field diversity with both vertical and horizontal polarization components. This gives the antenna diversity, frequency agility, low visibility, wide bandwidth and a low angle radiation pattern that is superior to traditional gain antennas in most applications.

Documents


Specifications

SKU TRABT1500
Manufacturer Part Number TRABT1500
Manufacturer Laird
Antenna Category VHF (132-220 MHz)
Working Frequency 150-168Mhz
Gain Unity
Antenna Style Phantom Low Profile
Polarity Dual Polarity
Bands Single
SISO or MIMO SISO
Directional or Omni Omnidirectional
Impedance 50 ohms
Max Input Power (W) 60 Watts
Horizontal/Azimuth Beamwidth 360
Height/Length (inches) 3.3 Inches
Height/Length (mm) 83.8 mm
Thickness/Diameter (inches) 3.25
Thickness/Diameter (mm) 82.6
Weight (lbs) 0.35
Weight (grams) 159.1
Material ABS Plastic
Operating Temp (celsius) (-40 C) to 85 C
Mount Style NMO-mobile mount
Color Black
Connector Type Connector - Bottom
Connector 1 NMO
Includes O-Ring
OK for Outdoor Use Yes
Vehicular Yes
Ground Plane Required Yes
Product Condition New
