S9025PLRASMAF 5x5 inch LHCP IP-67 Ultra Rugged RFID Antenna - Right Angle SMA Female

  • $219.45
    Unit price per

S9025PLRASMAF


0 in stock. Subject to factory lead time
Lead time:  Ships in 10-12 Weeks

Shipping calculated at checkout.

S9025PLRASMAF 5x5 inch LHCP IP-67 Ultra Rugged RFID Antenna - Right Angle SMA Female

More InfoSpecifications Reviews

The S9025P is a ultra-rugged IP67 rated Left Hand Circularly Polarized RFID Antenna. This antenna operates in the FCC 902-928 Mhz range and offers 5 dBic gain. Size is 5 x 5 inches with Fixed Right Angle SMA-Female Connector.

*A note about Antenna Polarity:
For most RFID applications, right and left hand polarity antennas may be used interchangeably.

***This item is subject to an MOQ of 3 pcs***



More Information


Specifications

SKU S9025PLRASMAF
Manufacturer Part Number S9025PLRASMAF
Manufacturer Laird
Working Frequency 902-928 MHz
Antenna Category RFID (865-928 MHz)
Bands Single
IP Rating 67
Polarity Left Hand Circular
Gain 5.5
Horizontal/Azimuth Beamwidth 100
Vertical/Elevation Beamwidth 100
Connector Type Connector - Rear
Connector 1 SMA-Female Right Angle
Height/Length (inches) 5.2
Height/Length (mm) 133
Operating Temp (celsius) -30 to +70
Thickness/Diameter (inches) 0.71
Thickness/Diameter (mm) 18
Width (inches) 5.2
Width (mm) 133
Weight (lbs) 0.8
Weight (grams) 370
Material ABS Housing
Mount Style 2 Stud
Includes washers and hex nuts
Product Condition New
