W1900: 1.9 Inch 2G/3G Cellular Pentaband Stubby Antenna - Right Angle SMA-Male

  • $5.83
    Unit price per

W1900


11 Can ship immediately
Volume Price Breaks
Quantity: Unit Price:
10 $5.25
25 $4.79
100 $4.31
250 $3.92
500 $3.54
1000 $2.99
2500 $2.86
Lead time for qty above 11:  Ships in 14-16 Weeks

Shipping calculated at checkout.

W1900: 1.9 Inch 2G/3G Cellular Pentaband Stubby Antenna - Right Angle SMA-Male

More InfoDocumentsSpecifications Reviews

The W1900, 1.9 inch penta band stubby 2G/3G cellular antenna operates on GSM and WCDMA frequencies for a variety of M2M and wireless applications.


More Information

Pulse W1900 4 inch penta band stubby antenna operates on GSM and WCDMA frequencies for a variety of M2M and wireless applications. Antenna measures a mere 49 mm / 1.9 inches tall and has an SMA-Male connector.

FEATURES

  • Ultra Small form factor
  • Antenna size 1.9 inch 49.5 mm tall
  • Lead free materials
  • RoHS Compliant Product
  • Connector Type: Right Angle SMA




Documents


Specifications

SKU W1900
Manufacturer Part Number W1900
Manufacturer Pulse
Antenna Category 3G/4G/LTE (698-2700 MHz)
Working Frequency 824 - 960 MHz
Gain 1dBi
Working Frequency 2 1710 - 2170 MHz
Gain 2 2dBi
Working Frequency 3 1920 - 2170 MHz
Gain 3 2.5dBi
Antenna Style Stubby Antenna
Polarity Linear
Bands Multi
SISO or MIMO SISO
Directional or Omni Omnidirectional
Impedance 50 ohms
Max Input Power (W) 5
Horizontal/Azimuth Beamwidth 360
Height/Length (inches) 1.9
Height/Length (mm) 49
Thickness/Diameter (mm) 10.4
Weight (grams) 11.1
Operating Temp (celsius) -30 to +75
Color Black
Connector Type Connector - Side Entry
Connector 1 SMA-Male
Product Condition New
