YF88001261NF: Laird Yagi Antenna for 880-960 MHz with N-Female Connector

  • $193.05
    Unit price per

YF880012-61NF


30 Can ship immediately
Volume Price Breaks
Quantity: Unit Price:
10 $185.81
25 $183.26
100 $178.34
250 $165.79
Lead time for qty above 30:  Ships in 10-12 Weeks

Shipping calculated at checkout.

YF88001261NF: Laird Yagi Antenna for 880-960 MHz with N-Female Connector

More InfoDocumentsSpecifications Reviews

YF88001261NF is a Yagi Antenna operating within 880-960 MHz frequency range. This design provides excellent performance and durability for point-to-point and multi-point / directional outdoor antenna application used by private organization and government agencies. These are typically used for transportation such as railroad switching, remote locations reporting examples that include oil fields, weather conditions and, meter data transmissions for utilities.


More Information

YF88001261NF is a Yagi Antenna operating within 880-960 MHz frequency range. This design provides excellent performance and durability for point-to-point and multi-point / directional outdoor antenna application used by private organization and government agencies. These are typically used for transportation such as railroad switching, remote locations reporting examples that include oil fields, weather conditions and, meter data transmissions for utilities.

Documents


Specifications

SKU YF88001261NF
Manufacturer Part Number YF880012-61NF
Manufacturer Laird
Antenna Category 900 MHz
Working Frequency 880-960 MHz
Gain 12.2
Antenna Style Yagi Antenna
Polarity Vertical
Bands Single
SISO or MIMO SISO
Directional or Omni Directional
Impedance 50 Ohm
Max Input Power (W) 200
VSWR: < X: 1 1.5:1
Front/Back Ratio (Db) 20 dB
Horizontal/Azimuth Beamwidth 54
Vertical/Elevation Beamwidth 47
Height/Length (inches) 24
Height/Length (mm) 610
Width (inches) 6.61
Width (mm) 168
Thickness/Diameter (inches) 3.11
Thickness/Diameter (mm) 79
Weight (lbs) 3.02
Weight (grams) 1370
Cable Type RG213/U
Cable Length (inches) 19.2
Cable Length (mm) 488
IP Rating IP67
OK for Outdoor Use Yes
Ground Plane Required No
Product Condition New
