Shotglass Omni Antenna For Cellular 4G/LTE, Band 71 & 5G. NMO Mount IP67, RSGB-4G/5G-3-NMO

  • $45.00
    Unit price per

RSGB-4G/5G-3-NMO


513 Can ship immediately
Lead time for qty above 513:  Ships in 10-12 Weeks

Shipping calculated at checkout.

Shotglass Omni Antenna For Cellular 4G/LTE, Band 71 & 5G. NMO Mount IP67, RSGB-4G/5G-3-NMO

More InfoDocumentsSpecifications Reviews

Shotglass Omni Antenna For Cellular 4G/LTE, Band 71 & 5G. NMO Mount IP67.

  • 617-960/1695-7125 MHz
  • 4G / 5G (LTE), Dual Band WiFi Support
  • Includes Band 71 (617- 698 MHz)
  • Omni radiation pattern
  • Average peak gain • 617-960 MHz 2dBi
  • 695-5925 MHz 5.5dBi
  • Average power rating 45W
  • Size Dia. 1.61” (40.9mm) Height 3.77” (95.9mm)


More Information

Applications

  • CBRS Bands 42 and 48 (3.4-3.7 GHz)
  • Utility boxes
  • Smart metering
  • IoT Devices

Documents


Specifications

SKU RSGB4G5G3NMO
Manufacturer Part Number RSGB-4G/5G-3-NMO
Manufacturer RFMAX
Antenna Category 3G/4G/LTE/5G (600-6000 MHz)
Antenna Style Low Profile Antenna
Polarity Vertical
Max Input Power (W) 45 Watts
Weight (lbs) 0.17 Lbs
Weight (grams) 76 grams
Operating Temp (celsius) -40° to +85° C
Color Black
Connector 1 NMO
IP Rating IP67
OK for Outdoor Use Yes
Vehicular Yes
Product Condition New
