PLC1669-Rev2: 164-170 MHz 9-Element Yagi Antenna for MOTUS Systems & ATS or Cell Track Radios. Hi-Gain with fixed N-Female Connector.

PLC1669-Rev2
0 in stock. Subject to factory lead time
Lead time:  Ships in 2-4 Weeks
Shipping calculated at checkout.
PLC1669-Rev2: 164-170 MHz 9-Element Yagi Antenna for MOTUS Systems & ATS or Cell Track Radios. Hi-Gain with fixed N-Female Connector.
PLC1669-Rev2: 164-170 MHz 9-Element Yagi Antenna for MOTUS Systems & ATS or Cell Track Radios. Hi-Gain with fixed N-Female Connector.

PLC1669-Rev2: 164-170 MHz 9-Element Yagi Antenna for MOTUS Systems & ATS or Cell Track Radios. Hi-Gain with fixed N-Female Connector.

More InfoDocumentsSpecifications Reviews

TEMPORARILY DISCONTINUED.  Try M-Squared or Sinclair.

PLC1669-Rev2 is at heavy duty fully welded, directional 9-Element Yagi antenna operating within 164-170 MHz frequency range and with a gain of 12.4 dBi for use in MOTUS Systems with ATS or Cell Track VHF Radios.

Coaxial cables sold separately-See Related items.

*Made in the USA*
This antenna is designed and commonly used for VHF data transmission and control stations as well as by Bird Observatories to track migratory birds.

More Information

PLC1669-Rev2 is at heavy duty antenna operating within 164-170 MHz frequency range and with a gain of 12.4 dBi. This antenna is designed and commonly used for data transmission, control station operations, as well as by Bird Observatories to track migratory birds.

Features

  • Designed for use with Cell Track / MOTUS Systems
  • Frequency: 164-170 MHz Gain: 12.4 dBi
  • Environmental Rating: Outdoor - IP67
  • Power: 250 Watts Max Input
  • Wind Load: 1.4sq.ft
  • ESD Protection: DC Grounded
  • Connector: N Female
  • Mounting bracket included



Documents

PCL1669-Rev2 Datasheet

We Also Recommend

YS4306-Rev2: Yagi for 434 MHz CTT / MOTUS Tracking Systems, 7 element, 10.4 dBi, N-Female Connector
In Stock
YS4306-Rev2
YS4306-Rev2: Yagi for 434 MHz CTT / MOTUS Tracking Systems, 7 element, 10.4 dBi, N-Female Connector
View Details
PT400-100-SBM-SNM: 100 Feet 400 Type Low loss Cable Assembly with BNC-Male and N-Male Connectors
PT400-100-SBM-SNM
PT400-100-SBM-SNM: 100 Feet 400 Type Low loss Cable Assembly with BNC-Male and N-Male Connectors
View Details
FG4305: Long Rang Outdoor Omni Antenna for 430-440 & 434 MHz CTT / MOTUS Tracking Systems
In Stock
FG4305
FG4305: Long Rang Outdoor Omni Antenna for 430-440 & 434 MHz CTT / MOTUS Tracking Systems
View Details
PT400-075-SBM-SNM: 75 Feet 400 Type Low loss Cable Assembly with BNC-Male and N-Male Connectors
PT400-075-SBM-SNM
PT400-075-SBM-SNM: 75 Feet 400 Type Low loss Cable Assembly with BNC-Male and N-Male Connectors
View Details
400 Type Low Loss Coax Cable - 25 Feet - N Male - N Male
In Stock
PT400-025-SNM-SNM
400 Type Low Loss Coax Cable - 25 Feet - N Male - N Male
View Details

Specifications

SKU PLC1669rev2
Manufacturer Part Number PLC1669-Rev2
Manufacturer RFMAX
Antenna Category VHF (132-220 MHz)
Working Frequency 164-170 MHz
Gain 12.4 dBi
Antenna Style Yagi Antenna
Polarity Dual Polarity
Bands Single
SISO or MIMO SISO
Directional or Omni Directional
Max Input Power (W) 250
VSWR: < X: 1 1.5:1
Horizontal/Azimuth Beamwidth 50
Vertical/Elevation Beamwidth 43
Height/Length (inches) 136
Height/Length (mm) 3460
Weight (lbs) 6
Weight (grams) 3000
Connector 1 N-Female
IP Rating IP67
OK for Outdoor Use Yes
Product Condition New
