PA912: 15x15 inch High Gain Linearly Polarized 902-928 MHz Panel Antenna For ISM or RFID

  • $72.00
    Unit price per

PA9-12


5 Can ship immediately
Volume Price Breaks
Quantity: Unit Price:
10 $66.30
25 $63.41
100 $60.77
250 $58.00
Factory lead time:  Ships in 4-6 Weeks

PA912: 15x15 inch High Gain Linearly Polarized 902-928 MHz Panel Antenna For ISM or RFID

More InfoDocumentsSpecifications Reviews

The PA9-12 is a Linear Polarized high-gain panel antenna that offers 12 dBiL of gain and operates in the ISM band of 902-928 Mhz. The unit measures in at 16 x 15 x 1.5 inches, has a Fixed N-Female rear connector and includes it's own basic wall/mast mounting hardware. In addition, the unit is outdoor rated and well suited for both 900 mhz ISM point to point /machine to machine radio communications, as well as FCC RFID applications.


More Information

The PA9-12 flat panel directional antenna by Laird offers high-gain in a thin, low- profile package. The antenna is constructed of an off white color UV resistant ASA plastic radome with an aluminum backplate. The antenna can be used in horizontal or vertical polarization. The included heavy duty pole mount bracket allows up or down tilt adjustment and the stainless steel hardware assures a long service life. The antenna can be wall or pole mounted. The PA9-12 comes with an integral N female connector standard.

FEATURES

  • High gain / low profile
  • Mast/wall mount kit included
  • Rugged IP67 rated weatherproof construction
  • Vertical or horizontal polarization

Documents


Specifications

SKU PA912
Manufacturer Part Number PA9-12
Manufacturer Laird
Product Condition New
Antenna Category RFID 902-928 MHZ FCC
Bands Single
IP Rating Weatherproof
Polarity Vertical
Gain 12
Horizontal/Azimuth Beamwidth 40
Vertical/Elevation Beamwidth 55
Connector Type Connector - Rear
Connector 1 N-Female
Height/Length (inches) 16.2
Height/Length (mm) 411
Operating Temp (celsius) -30 to +70
Thickness/Diameter (inches) 1.4
Thickness/Diameter (mm) 36
Width (inches) 14.7
Width (mm) 373
Weight (lbs) 3
Weight (grams) 1360
Material ABS Housing
Color White
Mount Style Mast or Wall
Includes Basic Wall / Mast Mount
