G420BN 10 Inch Tuf Duck Style Base Loaded Two Way Radio 1/2 Wave Antenna - 420 Mhz UHF

  • $22.61
    Unit price per

G420BN


0 in stock. Subject to factory lead time
Volume Price Breaks
Quantity: Unit Price:
25 $22.29
100 $20.90
250 $19.67
500 $18.32
Lead time:  Ships in 6-8 Weeks

G420BN 10 Inch Tuf Duck Style Base Loaded Two Way Radio 1/2 Wave Antenna - 420 Mhz UHF

More InfoDocumentsSpecifications Reviews

Laird Tuf Duck style G420BN base loaded two way radio 1/2 wave antenna for 420 Mhz UHF Communication - 10 Inches long with BNC Male connector.



More Information

The Laird G420BN "Tuf Duck" is a base loaded 1/2 wave antenna for UHF communication. It measures 10 inches long, operates at 420-450 MHz and offers 2.5dB Gain with BNC male connector. Operates at -40 to +85 C. Equivalent to Centurion Tuf Duck & Antenex.



FEATURES
• Base-loaded 1⁄2 wave flexible cable antenna
• Provides 2.5 dB gain over standard 1⁄4 wave antennas
• PVC coated exterior
• BNC Male connector


Documents


Specifications

SKU G420BN
Manufacturer Part Number G420BN
Manufacturer Laird
Antenna Category UHF (380-600 MHz)
Working Frequency 420-450 MHz
Gain 2.5
Antenna Style Rubber Whip Antenna
Polarity Vertical
Bands Single
SISO or MIMO SISO
Directional or Omni Omnidirectional
Impedance 50
Max Input Power (W) 50
VSWR: < X: 1 1.5
Horizontal/Azimuth Beamwidth 360
Height/Length (inches) 8.5
Height/Length (mm) 216
Operating Temp (celsius) -40 TO +85
Mount Style Screw On
Color Black
Connector Type Connector - Bottom
Connector 1 BNC-Male
OK for Outdoor Use Yes
Vehicular No
Ground Plane Required No
Product Condition New
