DASUTWC500NF: White Clarity Series Ceiling Mount for 2g, 3g, 4g(lte) and Wifi Band with N-Female Connector

  • $145.15
    Unit price per

DASUTWC500NF


0 in stock. Subject to factory lead time
Volume Price Breaks
Quantity: Unit Price:
10 $76.84
25 $73.59
100 $70.13
250 $69.21
500 $68.75
Factory lead time:  Ships in 4-6 Weeks

DASUTWC500NF: White Clarity Series Ceiling Mount for 2g, 3g, 4g(lte) and Wifi Band with N-Female Connector

More InfoSpecifications Reviews

Clarity series White ultra thin ceiling mount for 2g, 3g, 4g(lte) and wifi band with N-Female connector

-Ceiling Mount indoor omni antenna for T-Mobile 600 MHz 4G/LTE band (610-698 MHz)



More Information

Clarity series White ultra thin ceiling mount for 2g, 3g, 4g(lte) and wifi band with N-Female connector

Specifications

SKU DASUTWC500NF
Manufacturer Part Number DASUTWC500NF
Manufacturer Pulse
Product Condition New
Antenna Style Ceiling Mount
Antenna Category iDAS
Polarity Linear
Bands Multi
SISO or MIMO SISO
Directional or Omni Omnidirectional
Frequency 1 608-960 MHz
Gain 1 7
Frequency 2 1695-2200 MHz
Gain 2 7
Frequency 3 2300-2700 MHz
Gain 3 5
Impedance 50 Ohm
Max Input Power (W) 40
VSWR: < X: 1 2:01
Horizontal/Azimuth Beamwidth 360
Vertical/Elevation Beamwidth 100
Pim Rating (@ 2x20 W) -155
Height/Length (inches) 6.78
Height/Length (mm) 172.2
Width (inches) 9.41
Width (mm) 239
Weight (lbs) 1.65
Weight (grams) 750
Cable Length (inches) 19.5
Cable Length (mm) 500
Connector 1 N-Female
OK for Outdoor Use No
Vehicular No
Ground Plane Required No
