A4030C-71270: FCC SlimLine UHF Antenna with 2m SMA to RPTNC Connector

  • $215.00
    Unit price per

A4030C-71270


2 Can ship immediately
Lead time for qty above 2:  Ships in 2-4 Weeks

A4030C-71270: FCC SlimLine UHF Antenna with 2m SMA to RPTNC Connector

More InfoDocumentsSpecifications Reviews

A4030C-71270: FCC SlimLine UHF Antenna with 2m SMA to RPTNC Connector

Features:

  • Frequency Range: 864-869 Mhz / 902 - 928 Mhz
  • Polarization: Circular
  • Gain: 6.5 dBic
  • Connector: SMA to RPTNC

These antennas are terminated with SMA Female, please buy extension cables separately.



More Information

A4030C-71270: FCC SlimLine UHF Antenna with 2m SMA to RPTNC Connector from Times-7 is ideal for warehousing operations. This antenna has an environmental rating of IP65 along with fire retardant Kydex material. Along with its versatile and slim design, the A4030C provides high performance in industrial RFID applications.

These antennas are terminated with SMA Female, please buy extension cables separately.


Documents


Specifications

SKU A4030C71270
Manufacturer Part Number A4030C-71270
Manufacturer Times-7
Antenna Category RFID (865-928 MHz)
Bands Multi
IP Rating IP65
Polarity Circular
Gain 6.5 dBic
Horizontal/Azimuth Beamwidth 60
Vertical/Elevation Beamwidth 60
Connector Type Connector - Rear
Connector 1 SMA-Female
Connector 2 RP TNC-Male
Cable Length (inches) 78
Cable Length (mm) 2000
Height/Length (inches) 11
Height/Length (mm) 280
Operating Temp (celsius) -20 to 55
Thickness/Diameter (inches) 11
Thickness/Diameter (mm) 280
Width (inches) 0.5
Width (mm) 12
Weight (lbs) 1.6
Weight (grams) 750
Material Fire Retardant Kydex
Color Black
Product Condition New
