3-in-1 MiMo 5GNR/4G-LTE & GNSS Antenna for M2M, IoT, & Vehicular Applications. Includes 6 ft. Cables & SMA Connectors. R2SP-DB-G55-6-SSS-B
R2SP-DB-G55-6-SSS-B
Los gastos de envío se calculan en la pantalla de pagos.
3-in-1 MiMo 5GNR/4G-LTE & GNSS Antenna for M2M, IoT, & Vehicular Applications. Includes 6 ft. Cables & SMA Connectors. R2SP-DB-G55-6-SSS-B
More InfoDocumentsSpecifications Reviews
The RFMAX "R2SP" series antenna # R2SP-DB-G55-6-SSS-B is a compact, Low profile, direct-mount antenna designed for M2M machine-to-machine applications. The unit measures 3.15 x 2.91 inches, with a height of just 1 inch. This antenna was designed to exceed all 3G/4G/LTE/5G specifications from the major North American cellular carriers including AT&T, Verizon, Sprint & T-Mobile. This antenna is the perfect choice for NEMA enclosures, utility vehicles, or public safety vehicles,
More Information
Specifications
SKU | R2SPDBG556SSSB |
---|---|
Manufacturer Part Number | R2SP-DB-G55-6-SSS-B |
Manufacturer | RFMAX |
Antenna Category | 5G/4G (600-7125 MHz) |
Working Frequency | 617-960 MHz |
Gain | 3.2 dBi |
Working Frequency 2 | 1427-5690 MHz |
Gain 2 | 5.0 dBi |
Working Frequency 3 | 3300-5000 MHz |
Gain 3 | 5.1 dBi |
Working Frequency 4 | 5150-5925 MHz |
Gain 4 | 4.7 dBi |
Working Frequency 5 | 1575.42/1598-1606 MHz |
Gain 5 | 28 dB @ 2.7V |
Antenna Style | "Puck" Multi-Element Antenna |
SISO or MIMO | MIMO |
Directional or Omni | Omnidirectional |
Impedance | 50 ohms |
Max Input Power (W) | 25W |
VSWR: < X: 1 | <2:1 |
Height/Length (inches) | 3.15 |
Height/Length (mm) | 80 |
Width (inches) | 2.91 |
Width (mm) | 74 |
Thickness/Diameter (inches) | 1 |
Thickness/Diameter (mm) | 25.6 |
Weight (lbs) | 1 |
Material | UV Stable ASA |
Operating Temp (celsius) | -40 to +85 |
Color | Black |
Number of Cables | 3 |
Connector 3 | SMA-Male |
IP Rating | IP67, IP69 |
OK for Outdoor Use | Outdoor |
Ground Plane Required | No |
Product Condition | New |
