9-in-1 Covert Antenna, SMA Male on all lines 4x 5G/LTE, 4x WiFi-6E, 1x GNSS | R4WA-G454W-10-9S-B
R4WA-G454W-10-9S-B
Los gastos de envío se calculan en la pantalla de pagos.
9-in-1 Covert Antenna, SMA Male on all lines 4x 5G/LTE, 4x WiFi-6E, 1x GNSS | R4WA-G454W-10-9S-B
More InfoDocumentsSpecifications ReviewsThe RFMAX R4WA Series is a high-performance, 9-in-1 covert antenna solution optimized for the latest 5G and Wi-Fi 6E applications.
More Information
Specifications
| SKU | R4WAG454W109SB |
|---|---|
| Manufacturer Part Number | R4WA-G454W-10-9S-B |
| Manufacturer | RFMAX |
| Antenna Category | Multi-Band (Cellular, WiFi, and/or GPS) |
| Working Frequency | 617-7125 MHz |
| Gain | 3.6 - 4.6 dBi |
| Working Frequency 2 | 2400-7125 MHz |
| Gain 2 | 3.9-4.6 dBi |
| Antenna Style | "Wedge" Multi-Element Antenna |
| Directional or Omni | Omni Directional |
| Impedance | 50 ohm |
| Max Input Power (W) | 2 Watts |
| VSWR: < X: 1 | <2.0:1 |
| No Of Elements | 9 |
| Height/Length (inches) | 8.66 inches |
| Height/Length (mm) | 220 |
| Width (inches) | 3.15 inches |
| Width (mm) | 80 |
| Weight (grams) | 420g |
| Operating Temp (celsius) | -40°C to + 85°C |
| Mount Style | Adhesive Mount |
| Color | Black |
| Cable Type | LL-195/RG-174 |
| Number of Cables | 9 |
| Cable Length (inches) | 120 |
| Connector 1 | SMA-Male |
| Connector 2 | RP SMA-Male |
| Connector 3 | SMA-Male |
| IP Rating | IP65 |
| OK for Outdoor Use | Indoor |
| Product Condition | New |
